2010 Gulfstream G150

2010 Gulfstream G1503

2010 Gulfstream G1501

2010 Gulfstream G1502

2010 Gulfstream G150

0 0 reviews

GULFSTREAM G SERIES

Save

The Gulfstream G150 is a business jet manufactured by Gulfstream Aerospace. It was first introduced in 2005 and is based on the successful Gulfstream G100 (formerly the IAI Galaxy). The G150 is the last of the G100 series and is the most advanced model. It is powered by two Honeywell TFE731-40AR-200G engines, each producing 4,660 pounds of thrust. The G150 has a maximum cruise speed of 486 knots and a range of 2,400 nautical miles. The cabin is spacious, with seating for up to eight passengers in a double-club configuration. The G150 also features an improved avionics suite, including an integrated autopilot system, a digital pressurization system, and a synthetic vision system. The G150 was produced until 2013, when it was replaced by the G200.

TT: 4,335.8
Landings: 2,356
C of A Date: May 21, 2009
Entry to Service: April 12, 2010
Regulation: FAR Part 91.409(F)(3)
Location: Ft. Lauderdale, FL (KFXE)
Enrolled on CMP Maintenance Tracking Program
Engine(s)
Honeywell TFE731-40AR-200G
TT: 4,335.8 / 4,335.8
Cycles: 2,356 / 2,356
SN: P-26261 / P-26262
Enrolled on Honeywell MSP Gold Program
APU Details
Honeywell RE100CS (G150)
TT: 1,490.8
Cycles: 3,791
SN: P-472
Enrolled on Honeywell MSP Gold Program
Avionics
Collins Pro Line 21 Avionics Suite w Paperless Cockpit Option
Collins IFIS-5000 Electronic Chart Display System
Dual Collins FMC-6100 Flight Management System (w Vspeed database)
Dual Collins FGC-3000 Flight Guidance Computers
Triple Collins VHF-4000E Comm. Units
Dual Collins TDR-94D Transponders w Mode S and ADS-B Out V2
Dual Collins DME-4000 Receivers
Dual Collins RIU-4110 Radio Interface Units
Collins TWR-850 Turbulence Weather Radar
Dual Collins HF-9000 HF Comm.
Collins TCAS-4000 TCAS II w Change 7.1
Four EFIS Adaptive Flight Displays
Collins IFIS w Dual Collins File Server Units STC
Dual Collins CDU-6200 FMS Controllers
Dual Collins GPS-4000A GPS Receivers
Dual Collins NAV-4000 /4500 Units
Dual Collins ADC-3010 Air Data Computers
Dual Collins AHS-3000 AHRS System
Dual Collins ADF System
Collins DCU Data Concentrator Unit
Collins ALT-4000 Radio Altimeter
120 Min CVR w/ 90-Day Battery (Mod 4) & Underwater Locator Beacon
Emergency Power Annunciator STC
Honeywell MK V EGPWS w Windshear
Third Collins VHF Comm. W Data Link STC
ARTEX C406-N ELT w/Nav. Interface
Honeywell AR 256 Flight Data Recorder STC
XM Antenna STC
Maintenance Status
1C / 12 Month: January 2022: January 2023
2C / 24 Month: August 2022: August 2024
3C / 36 Month: January 2021: January 2024
4C / 48 Month: January 2021: January 2025
6C / 72 Month: August 2020: August 2026
8C / 96 Month: June 2017: June 2025
12C / 144 Month: January 2021: January 2033
16C / 192 Month: NA: April 2026
1A / 500 Hour: January 2021: 4,755.4 Hours
2A / 1,000 Hour: January 2021: 4,918 Hours
3A / 1500 Hour: December 2021: 5,755.4 Hours
4A / 2,000 Hour: January 2021: 5,918 Hours
5A / 2,500 Hour: June 2017: 4,930 Hours
6A / 3,000 Hour: August 2018: 6,000 Hours
8A / 4,000 Hour: January 2021: 7,918 Hours
10A / 5,000 Hour: NA: 5,000 Hours
20A / 10,000 Hour: NA: 10,000 Hours
Features/Options
ICG Iridium SATCOM w/ 2 Handsets (Flight Deck / Cabin)
Maintenance Diagnostic Computer
Dual Cursor Control Device (CCD)
Collins Graphical Weather
Collins FMS 3D Map
Dual Cursor Control Device
EICAS
Electronic Jeppesen Charts & Map Overlays
Collins Electronic Checklist
Aft Emergency Battery
RAM Air
RVSM Capable
Emergency Locator Transmitter (ELT)
Passenger Life Vests
Long Range Oxygen Bottle
Therapeutic Oxygen Outlet & Mask
Passenger Oxygen
Protective Breathing Equipment (PBE)
First Aid / Medical Kit
RosenView Passenger Info System
Five (5) Plug-In 6.5-Inch Cabin Monitors
One Color Touchscreen Remote Control
Three (3) 110V Outlets
Dual DVD Players
Headphone Controls at each Seat
Cabin Management System (CMS)
ICG NxtMail Server (Connect Up to 10 Devices in Cabin)
